It’s like adding a turbocharger to Electronic Control Module downloads and uploads. Cummins new INLINE 7 Data Link Adapter has a faster processor, more robust algorithms, larger memory buffers and more sophisticated filtering than previous models while simultaneously accessing multiple vehicle data channels. INLINE 7 supports USB, WiFi and Bluetooth technologies in a single device. INLINE 7 communicates with your PC and is designed for future capability with mobile products.
The INLINE 7 Data Link Adapter is designed to function with a wide array of Cummins, OEM and third-party service and information tools, including the following:
The INLINE 7 data link adapter communicates with your PC using a Universal Serial Bus (USB) through a standard USB connector as well as through WiFi or Bluetooth. INLINE 7 is fully compliant with the Technology and Maintenance Council’s RP1210 standard and supports three simultaneous CAN connections and offers baud rates of 250k, 500k and 1 megabaud. INLINE 7 supports several other protocols such as J1708, J1587, ISO 15765, ISO 9141 (K and L line).
Industrial-Strength Design.
Cummins INLINE 7 Data Link Adapter incorporates strain relief secure cables for a robust connection. The rugged carrying case provides extra protection for the most demanding service environments. The main unit comes with a full one-year warranty against software and hardware malfunction.
Every Detail. Covered.
Everything you need from locking USB cable, 6-Pin, and 9-Pin Deutsch Wye adapter with security chip, and rugged storage case is included in the complete INLINE 7 kit.
Reviews
-
Five Stars
If you need to use Cummins Insite diagnostic software, this is adapter to buy! Comes with all the cables you need to work on every Cummins engine (except Ram and NIssan).
-
Five Stars
SO FAR WORKS GREAT
-
Five Stars
Have not used yet but heard nothing but good things about the product.
