Navistar Diamond Logic Builder OEM Software

NAVISTAR® DLB FLEET

Diagnostic Software

International® Diamond Logic® Builder Fleet

Basic Functions

• Read Fault and clear diagnostic fault codes
• View vehicle parameters and features

Advanced Features

• Bi-directional control of electrical components
• View switch location and cluster configuration
• View wiring diagrams
• Automatic module detection<
• Graph parameters<
• Record snapshots

Compatible Vehicles

• International® 4200/4300/4400 Series
• International® 7000 Series
• International® 8000 Series
• International® CF Series (Cluster faults, Test all gauges except fuel, Odometer reset)

Diamond Logic Builder™ (DLB) provides high performance diagnostics for the electrical systems on high performance International trucks and IC Buses. DLB Fleet displays vehicle signals in graphical and text format. This software also reads and displays vehicle diagnostic trouble codes as well as vehicle features and parameters.

Minimum Requirements:

• 150MB of free hard disk space
• An Internet connection

Recommended Requirements:

• Pentium 4 class process with a minimum 1 GHz of speed
• 512 MB of RAM
• 150MB of free hard disk space
• Operating System of Windows 7, XP, 2000 or Vista
• One or more RP1210A compatible communication devices
• Any type of high speed Internet connection

Recommended Adapters:

• NEXIQ™ Technologies – USB­Link2
• Dearborn Group Technologies – DPA IV, DPA IV+
• Noregon® Systems, Inc. – DLA+, DLA+ Wireless

Communication Link Drivers:

• DLB uses standard RP1210A drivers for communication. The drivers are specific to the communications device and are not installed with DLB.

User Permissions:

Diamond Logic Builder has different tiered permission levels allowing for more advanced use of the software.

• Level 1 (Diagnostics) – L1 is included with active product key.
• Level 2 (Diagnostics and Parameter Programming) – L2 access requires completion of web based training for each user.
• Level 3 (Diagnostics, Parameter Programming and Advanced Logic) – L3 access requires completion of Instructor Led training for each user.
